Using Optenni Lab’s innovative assessment tools antenna and RF designers can quickly evaluate, compare and rank new antenna designs. The tools reveal the theoretical upper limits for the wireless performance.
Optenni Lab increases the productivity of antenna and RF designers by quickly and accurately synthesizing matching circuits using realistic layout models and vendor library component models for capacitors and inductors.
Optenni Lab is designed to maximize the wireless performance taking into account various loss sources and layout effects. Robust designs with respect to varying usage environment of the antenna can automatically be synthesized.
OPTENNI LAB EDITIONS
Optenni Lab is available in two editions: Standard and Professional. The optional Array Module is for advanced multiantenna system optimization.
TUNABLE ANTENNA DESIGN
Optenni Lab is widely applied in the optimization of tunable antennas, which typically are either frequency tunable antennas using aperture tuners or use closed loop tuners which adapt to various user environments. Optenni Lab supports switches, variable capacitor banks and more complex tuner chips as the tunable elements. Optenni Lab can calculate the exact radiation efficiency and radiation patterns of the antenna system as a function of the aperture components.
Read more >
